Pellet Mill 200mm Electric 7.5kW for Alfalfa and Forage
The MKFD200B electric pellet mill is designed to process alfalfa, grasses, and forages into high-density, nutritious pellets, ready for storage and use as balanced feed. Its interchangeable flat die allows you to change pellet diameter according to diet or animal type, providing flexibility and quality in every batch.
Details:
Alfalfa Pellet Mill 200mm – MKFD200B
The MKFD200B electric pellet mill is designed to process alfalfa, grasses, and forages into high-density, nutritious pellets, ready for storage and use as balanced feed. Its interchangeable flat die allows you to adjust pellet size according to the diet or animal type, ensuring flexibility and quality in every production.
Raw Material Preparation
To achieve excellent pellet quality, certain conditions must be met:
- Ideal moisture: between 9% and 17%.
- Sun-dried alfalfa: best suited for the process.
- Do not use freshly cut alfalfa: contains too much moisture.
- Overly dry alfalfa: can be rehydrated with a slight addition of water.
- Pre-grinding: forage must be ground to a size smaller than the pellet diameter. Example: for 8 mm pellets, grind material to 7 mm.
If the fiber is too long, pellet appearance suffers and the machine works harder, reducing output.
Possibility to Enrich the Formula
The MKFD200B allows you to combine alfalfa with other concentrates or additives up to 40%, creating more complete and nutritious diets.
Excellent results have been achieved with:
- Corn, soy, and oats.
- Bone meal.
- Vitamin and mineral premixes.
- Salt and shell grit.
For homogeneous mixtures, it is recommended to use a horizontal mixer before feeding the raw material into the pellet mill.
Safety and Electromechanics
The MKFD200B features safety and electrical control systems for reliable operation:
- Direct start with thermal switch (7.5 kW).
- Motor protector to safeguard the equipment against overload.
- Emergency stop button (punch type).
- Phase control: prevents operation if a phase is missing.
- Voltage and amperage meters for real-time monitoring.
- Epoxy-painted steel electrical cabinets, CE compliant.
Robust Construction
- Modular cast iron frame for high strength.
- Rollers and dies made of hardened SAE steel, designed for maximum durability.
- Baked paint with anti-corrosion treatment for extended service life.
Easy Maintenance
The design is practical so users can perform maintenance without third-party assistance:
- Periodic bearing lubrication.
- Gearbox oil change once a year.
Spare Parts and Warranty
- All parts are manufactured by MEELKO and available directly from the factory.
- 3-year warranty on the structure.
- 12-month warranty on rollers, dies, and shafts against manufacturing defects.
Technical Specifications
- Capacity: 150–200 kg/h
- Power: 7.5 kW (three-phase)
- Package weight: 150 kg
- Dimensions: 1050 × 480 × 990 mm (0.499 m³)
Includes
- Flat die extractor.
- Maintenance and assembly tool kit.
- Manual grease gun.
Advantages of Pelleted Alfalfa
- Long shelf life: up to 5 years without loss of quality.
- Higher added value: pellets are more profitable than baled alfalfa.
- Balanced feed: nutritious and easy to dose.
- Profitability for small and medium farms.
Support and After-Sales
At MEELKO we offer not only the machine, but also technical advice and support during the learning process, ensuring every customer can produce quality pellets from day one.
With our after-sales service, users have ongoing support, quick access to spare parts, and guidance to confidently start their pellet business.
Technical Specifications
Applications:
This product is ideal for the following industrial applications:
Warranty and Support
All our products include complete warranty and specialized technical support. Our team is available to help you with any consultation or maintenance need.
General Information
| Product Name | : | Pellet Mill 200mm Electric 7.5kW for Alfalfa - MKFD200B |
| Price | : | $3,142.00 |
| Subcategory | : | Alfalfa pellet mills |
| Category | : | Pellet Mills |
Technical Specifications
| Power | : | 7.5 kW |
| Capacity | : | 150 kg/hr |
| Dimensions | : | 1050*480*990 mm |
| Weight | : | 150 kg |
| Humidity | : | 17% |
