Pellet Mill 200mm Electric 7.5 kW for Animal Feed – MKFD200C
Details:
MKFD200C Electric Pellet Mill: Efficient Animal Feed Pellet Production
The Meelko MKFD200C electric pellet mill is the reference machine for livestock farmers, ranchers, and small feed production plants that want to manufacture their own animal feed pellets economically, hygienically, and with full quality control. Featuring a 200 mm flat die and a 7.5 kW electric motor, this compact unit transforms raw materials such as ground corn, soybean, wheat, straw, hay, alfalfa, concentrate blends, and agro-industrial by-products into uniform, nutritionally dense pellets. In-house feed production allows producers to significantly reduce feeding costs and maintain precise control over the nutritional profile of the feed supplied to their animals.
Technical Specifications of the MKFD200C
The heart of the MKFD200C is its flat die and roller pelleting system with a 200 mm die diameter. The stainless steel or treated carbon steel die ensures a long service life even when processing abrasive raw materials. The three-phase 7.5 kW electric motor transmits power to the main shaft via a high-strength V-belt and pulley system. Production capacity ranges from 80 to 120 kg/h depending on the feed formula, raw material moisture content, and selected pellet diameter. Dies are available in various hole diameters (2, 3, 4, 6, 8 mm) to suit the nutritional requirements of poultry, rabbits, pigs, cattle, sheep, and fish.
Compatible Raw Materials and Feed Formulas
The versatility of the MKFD200C is one of its greatest strengths. The unit can process cracked or ground corn, wheat, sorghum, ground soybeans, soybean meal, rice bran, wheat bran, ground straw, dry hay, alfalfa, sunflower husks, beet pulp, molasses (in small proportions), vitamin and mineral premixes, and protein concentrates. The key to optimal pelleting is adjusting the mixture moisture to the 14-17% range, which allows the pellets to achieve the necessary cohesion without artificial binders. The operation manual includes base formulas and formulation recommendations for different animal species.
Advantages of Making Your Own Animal Feed
Producing feed directly on the farm with the MKFD200C offers multiple economic and productive advantages. First, it eliminates distribution margins and finished feed transport costs, reducing the cost per kilogram by 20% to 40% depending on the region. Second, the producer has full control over formulation, allowing adjustment of protein, energy, fibre, and micronutrient contributions according to the animal's productive stage. Third, pelleted feed has better palatability and feed conversion than powdered or mixed feed, resulting in greater weight gain and less waste. Finally, the pellet format reduces dust in the barn or poultry house, improving the respiratory health of the animals.
Installation, Start-Up, and Operation
The MKFD200C is installed on a flat, level surface without the need for permanent anchoring due to its compact weight. Electrical connection is three-phase 220V or 380V depending on the available version. Starting is direct or star-delta to reduce the initial current peak. Operation is straightforward: load the feed hopper with the pre-prepared moist mixture, adjust the feed rate via the regulating screw, and the pellets fall directly into a container below the outlet. Initial warm-up time is approximately 5-10 minutes with a new die before achieving optimal-quality pellets. The operation manual includes start-up sheets, adjustment tables, and troubleshooting guides.
Maintenance of the MKFD200C
Maintenance of the MKFD200C pellet mill is straightforward and low-cost. Routine tasks include: cleaning the pelleting chamber after each work session, bearing lubrication according to Meelko's recommended schedule, checking the condition of rollers and die, and adjusting the roller-to-die clearance to maintain optimal compaction pressure. The die and rollers are the highest-wear components and are supplied as standard spare parts with immediate availability. Meelko recommends keeping a spare set of rollers and a die in stock to ensure production continuity in the event of unexpected wear. The complete unit can be disassembled for thorough cleaning in under 30 minutes.
Safety and Ergonomic Design
The MKFD200C has been designed with operator safety as a priority. The pelleting chamber is covered by a protective housing with a safety interlock that stops the motor if opened during operation. External moving parts are protected by sheet-metal covers to prevent accidental contact. The feed system features a variable-speed auger that prevents sudden motor overloads. Noise levels are moderate and within acceptable limits for use in livestock facilities. All surfaces in contact with the feed are made from food-grade materials.
Warranty, Spare Parts, and Meelko Technical Support
Meelko backs the MKFD200C pellet mill with a 12-month warranty covering manufacturing defects and materials. The equipment is delivered with an operation and maintenance manual in English, a recommended spare parts list, a die assembly and disassembly tool kit, and a factory test certificate. Meelko's technical team provides advice on feed formulation, die selection by animal species, and moisture management of locally available raw materials. After-sales service covers remote assistance, availability of original spare parts, and on-site technical support visits. Invest in the MKFD200C and take the first step towards self-sufficiency in animal feed production on your farm.
Technical Specifications
Applications:
This product is ideal for a wide range of industrial applications, including:
• Material processing
• Industrial production
• Manufacturing operations
• Automation systems
• Construction projects
Warranty and Support
All our products include complete warranty and specialized technical support. Our team is available to help you with any consultation or maintenance need.
General Information
| Product Name | : | Pellet Mill 200mm Electric 7.5 kW for Animal Feed – MKFD200C |
| Price | : | $3,142.00 |
| Subcategory | : | Animal feed |
| Category | : | Pellet Mills |
Technical Specifications
| Power | : | 7.5 kW |
| Capacity | : | 150 kg/hr |
| Dimensions | : | 1050*480*990 mm |
| Weight | : | 150 kg |
| Humidity | : | 20% |
