MKFD200R – 200 mm Roller Rotation Biomass Pellet Mill
The MKFD200R Roller Rotation pellet mill from Meelko is engineered for hardwoods, ultra-dry biomass, low-lignin agricultural residues and materials that lack natural binding, where traditional die-rotation (C-type) pellet mills lose traction or fail to compress properly.
Details:
MKFD200R – 200 mm Roller Rotation Biomass Pellet Mill
High-pressure pelletizing for hardwoods, dry biomass and low-cohesion materials
The MKFD200R Roller Rotation pellet mill from Meelko is engineered for hardwoods, ultra-dry biomass, low-lignin agricultural residues and materials that lack natural binding, where traditional die-rotation (C-type) pellet mills lose traction or fail to compress properly.
In the R-type system, the rollers rotate over a fixed die, delivering:
- Much higher compression force
- Strong traction on difficult materials
- Deeper mechanical engagement
- Denser, stronger pellets
- Consistent performance with challenging feedstocks
Although the output is lower than a C-type machine, the MKFD200R pelletizes materials that a standard system simply cannot handle.
Why choose a Roller Rotation (R-Type) pellet mill?
Extreme compression for demanding biomass
The MKFD200R is ideal for feedstocks that typically:
- Slip on C-type dies
- Fail to compact
- Produce dusty or fragile pellets
Recommended for:
- Hardwoods and semi-hard woods
- Very dry sawdust
- Fibrous biomass
- Low-lignin agricultural residues
- Materials with minimal natural adhesion
Superior pellet density and strength
The R-type system produces pellets that are:
- Heavier and more compact
- More uniform
- Less brittle
- Lower in fines and dust
Excellent traction, even with dry material
The roller-rotation mechanism ensures stable feeding when working with:
- Over-dried sawdust
- Irregular particles
- Low-moisture biomass
- Non-cohesive material blends
Production capacity
Because the R-type runs at a slower working speed, it generates about 50% of the output of an equivalent C-type machine.
Typical performance for the MKFD200R:
- Mixed biomass: 99–143 lb/h
- Hardwoods: 77–110 lb/h
- Low-cohesion dry materials: 55–88 lb/h
(1 kg = 2.20462 lb)
Recommended materials
Wood biomass
- Dry pine, eucalyptus, poplar
- Hardwood sawdust (oak, guatambú, quebracho, etc.)
- Fine and coarse shavings
- Carpentry residues (pre-milled)
Agricultural residues
- Peanut shells
- Sunflower hulls
- Dried bagasse
- Crop waste
- Dried pruning residues
Difficult or low-binder materials
- Over-dried biomass
- Fiber-rich mixtures
- Irregular particle blends
- Materials with very low adhesion
Technical advantages of the MKFD200R
- Roller Rotation system, maximum torque and compression
- 200 mm fixed die made of heat-treated SAE steel
- Reinforced compression chamber for abrasive biomass
- Cast-iron body, stable and vibration-resistant
- Industrial baked anticorrosive coating, durable in dusty environments
- Fast access to rollers and die, easy maintenance
Natural limitation of the R-Type system
- Lower hourly production, but
- The only system capable of pelletizing extremely difficult materials
In simple terms:
C-Type = more speed
R-Type = more pressure
For hardwoods and problematic biomass, the R-Type is the professional solution.
Material preparation guidelines
For best pellet quality:
- Moisture: 8–12%
- Particle size: 3–5 mm
- Biomass must be fully dried
- Remove stones, metals or debris
- Mix materials evenly when using blends
Technical Specifications – MKFD200R
- Die diameter: 200 mm
- Working system: Roller Rotation (R-Type)
- Capacity: 55–143 lb/h depending on material
- Power requirement: 7.5–11 kW
- Weight: 485–573 lb
- Dimensions: 37.4 × 17.7 × 35.4 in
Includes die extractor, tool kit and manual grease pump.
The compact high-pressure pellet mill for hard biomass
The MKFD200R is ideal for producers working with:
- Hardwoods
- Very dry biomass
- Low-binder agricultural residues
- Tough, non-cohesive materials
Where a C-Type fails, the R-Type performs flawlessly.
Technical Specifications
Applications:
This product is ideal for a wide range of industrial applications, including:
• Material processing
• Industrial production
• Manufacturing operations
• Automation systems
• Construction projects
Warranty and Support
All our products include complete warranty and specialized technical support. Our team is available to help you with any consultation or maintenance need.
General Information
| Product Name | : | MKFD200R – 200 mm Roller Rotation Biomass Pellet Mill |
| Price | : | $5,550.00 |
| Subcategory | : | R-type Pelletizers |
| Category | : | Pellet Mills |
Technical Specifications
| Power | : | 7.5 kW |
| Capacity | : | 150 kg/hr |
| Dimensions | : | 1050*480*990 mm |
| Weight | : | 150 kg |
| Humidity | : | 20% |
